Specifications
1.Rating：2A/36VDC.
2.Electrical Life：
100,000 Make-And-Break Cycles At Full Load.
3.Insulation Resistance ：1,000MΩ Min. at 500VDC.
4.Delectric Strength：2,000V RMS@sea level.
5.Contact Resistance：
50mΩMax.@1A/12VDC(inital value).
6.Operation Temperature ：-20℃+70℃.
7.Operation Pressure：4.5±1.5N.
8.Travel：About 2.3mm.
9.Ingress Protection：IP67.
10.Torque：11.5 kgf·cm.
11.Current limiting resistor is required to limit
LED forward current to 20mA.
12.CAP Keeps same high.
13. 13.Push-OFF,LED Red light,Push-ON,LED Green light(Latching)
