SPECIFICATIONS
CONTACT RATING: AC 125V 6A, AC 250V 3A , DC 30V 3A
MECHANICAL LIFE: 200,000 make – and – break cycles DC 10V & 0.1 mA.
CONTACT RESISTANCE: 10 mΩ max.
INSULATION RESISTANCE: 500V 500MΩ MIN.
DIELECTRIC STRENGTH: 1,000Vrms min@sea level.
OPERATING TEMPERATURE: -30℃- 85℃
WATER – RESISTANCE:100 make-and-break cycles min at 10 cm depth
MATERIALS
CASE: Diallyl phthalate (DAP)(UL94V-0).
ACTUATOR: Brass,chrome plated.
BUSHING: Brass, nickel plated.
HOUSING: Stainless Steel.
SWITCH SUPPORT: Brass ,tin plated.
CONTACTS/TERMINALS: Brass,with Silver or gold plated
