超小型防水船形開關(guān)

SPECIFICATIONS
CONTACT RATING: Dependent upon contact material.
MECHANICAL LIFE: 30,000 make – and – break cycles.
CONTACT RESISTANCE: 2Ωmax .initial @ 2-4VDC 100mA for both silver and
gold platedcontacts.0 m
INSULATION RESISTANCE: 1,000MΩ min.
DIELECTRIC STRENGTH: 1,000V RMS@sea level.
OPERATING TEMPERATURE: -30℃ to 85℃.

MATERIALS
CASE & BUSHING: Glass filled nylon 6/6, flame retardant,heat stabilized (UL94V-0).
ACTUATOR: Nylon, black std.Internal O-ring seal standard with all actuators.
SWITCH SUPPORT: Brass or steel, tin plated.
CONTACTS/TERMINALS: Silver or gold plated copper alloy
